HNGRYnsite – your fridge camera

• 1x HNGRYnsite powered by Liebherr
• 3x different holder sizes
• 1x USB-C cable
• 3x adhesive strips for fixing
• 1x metal pin to reset your HNGRYnsite

In order to make full use of the functions of the HNGRYnsite powered by Liebherr, the following requirements must be met:

• You have a refrigerator with door racks in which you can place your HNGRYnsite camera. Thanks to the different holder sizes, it will fit in any refrigerator – only extremely wide units, such as French doors, may have restrictions.
• You have an Android or iOS enabled smartphone with internet access.
• You have our HNGRY app installed on your smartphone.
• Available languages: DE, EN, ES, EL, BG, SL, SK, RO, HU, FR, IT, CS, PL.
• The camera is battery-powered and therefore requires no additional cabling. A USB-C charging cable is included in the scope of delivery.

Other technical requirements for your home network and router:

• IEEE 802.11 b/g/n with 2.4 GHz

No, you can also use your HNGRYnsite without xtraHNGRY and the best thing is: you even get xtraHNGRY for free for a whole year when you buy your HNGRYnsite camera.

The camera can currently be purchased via our webshop in DE, AT, UK (excluding Northern Ireland) and from the respective dealer. The billing and delivery address must also correspond to these available countries. Your country is not listed? Please write to us: feedback@iamhngry.com

Depending on the size of the fridge, your HNGRYnsite fridge camera can capture almost everything. Only the fruit and vegetable compartment and the fridge door cannot be captured by the camera. But this can be easily solved by using xtraHNGRY, which is included with the purchase of your camera for 1 year. This way you can manage your food storage easily! You can find more about xtraHNGRY here.

Simply scan the QR code enclosed in the package or click here and you will be guided step-by-step through the installation process, including videos, in the HNGRY app. Alternatively, if you have already installed the HNGRY app and registered, you can also start the installation process via the storage. Click on the menu in the storage (upper right icon with the three dots) and then on “Add HNGRYnsite” – off you go!

You can integrate up to ten HNGRYnsite cameras via the HNGRY app. Each camera works independently and provides you with the image of its viewing area. When placing the cameras, bear in mind that the camera image may be influenced by the flash of another camera.

Energy efficiency is important to us: the HNGRYnsite battery is extremely powerful and the camera’s functional concept is designed to be very energy-efficient. It is inactive when the door is closed to save energy. How long the battery life is ultimately depends heavily on how often you open your fridge and for how long. With average use, the battery life is three months.

To charge your HNGRYnsite, remove it from the cradle and connect it to a power outlet using the included USB-C charging cable and a USB power adapter (not included). The battery is recharged and ready for use within a few hours. When fully discharged, it takes up to six hours to fully recharge. Note: The power adapter should have a power of at least 2A and a supply voltage of 5V DC (direct current) for fast charging. Mains adapters with lower power will increase the charging time.

You can check the battery status of your camera in the HNGRY app. Simply click on the camera image and scroll down. Under “Battery” you can see the charge level in %. If the camera’s LED lights up red or the battery level in the HNGRY app shows a low charge level, it is time to charge it.

The battery is permanently installed in the HNGRYnsite camera and therefore cannot be replaced. o charge your HNGRYnsite, remove it from the cradle and connect it to a mains socket using the USB charging cable supplied and a USB power supply unit (not included). You can find more information here.

Small electrical items to be disposed of are classed as WEEE – waste electrical and electronic equipment. The crossed-out waste bin indicates that the item must not be disposed of with normal household waste and must be collected separately, as it can be recycled. Sending these items to landfill can contribute to air and water pollution, as they can leak hazardous chemicals. Own disposal You can either dispose of your HNGRYnsite yourself at a designated collection point or simply send it back to us:

Dispose of it yourself You can dispose of your camera free of charge at local recycling centres. Note: The following batteries are included in the HNGRYnsite camera: Lithium-ion battery (Li-Io) This must be removed for proper disposal. Click here for disassembly instructions and battery removal.

On our support page you will find helpful tips on how to improve the quality of your images. If that doesn’t help, feel free to send us a bug report of your HNGRYnsite via the settings in the HNGRY app.

Due to the cold in the refrigerator, the glue of the sticky pad hardens, causing your HNGRYnsite holder to stay firmly in place. However, if you want to remove the holder for cleaning or other reasons, it’s best to use a hairdryer to warm up the area. The holder and the sticky pad should then come off easily.

Your HNGRYnsite camera is not working as usual? Our experts provide fast support! In case of a repair or complaint, simply contact Liebherr customer service:

• By email: service.cz.@liebherr.com
• By phone: +42 0 515 247 522

Please activate the DHCP mode for your router. As this is different for every router, please check your router’s network settings individually for the option “Activate DHCP server.

Our product “HNGRYnsite powered by Liebherr” complies with the regulations of the European Directives 2014/53/EU and 2011/65/EU. You can find the full text of the EU declaration of conformity here.

You can easily access the open-source software via a web server – here’s how: If you have not yet installed your HNGRYnsite yet:

1. Switch on your HNGRYnsite (blue flashing).
2. Establish a WLAN connection to your HNGRYnsite by searching for the camera via any end device with WLAN.
3. Open the following address in the browser: http://192.168.43.1:8000/oss

If you have already installed your HNGRYnsite:

1. Charge your HNGRYnsite using the USB-C cable supplied.
2. While charging, call up the IP address of your router at home (see your router’s user manual).
3. Find the IP address of your HNGRYnsite. You will find this in the network connections of your router (e.g. 192.168.2.101).
4. Then open the following address in your browser: IP address of your HNGRYnsite + “:8000/oss.html” (e.g. http://192.168.2.101:8000/oss).

Important: Make sure that your HNGRYnsite is in the same network as the end device with which you open the browser.

Note: If the HNGRYnsite is in your fridge, the camera will be inactive most of the time and therefore will not respond to the browser request.

SAR Warning (Power Consumption≥13dBm=20mW) This product complies with EU requirements regarding restriction of exposure of persons to radio-frequency energy (RF) emitted by telecommunication and radio devices as it is designed and manufactured in such a way as not to exceed the exposure limits indicated by the European Union Commission. The permitted SAR limit for the general population is 2.0 W/Kg. This limit guarantees an ample safety margin that protects all persons regardless of age and health condition.

Battery Warning

• Do not make any modifications to the camera. It is not possible to replace the camera battery. The battery can be removed in case of disposal (here you can find further information)
• Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery that can result in an explosion
• Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas
• A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas.
• Please dispose the battery according to our instructions here.

Image sensor

The main use-case of the HNGRYnsite is taking a picture of the inside of the fridge using an image sensor with a suitable lens. The image sensor is mostly inactive, it is only activated when the movement of the camera is considered to be regular. The image sensor takes a picture after a software trigger and is deactivated after the picture is taken.

Gyroscope & accelerometer

Detecting the movement and orientation A combined sensor is used to detect the movement and orientation of the device. It combines a tri-axial gyroscope and a tri-axial accelerometer in one housing. The sensor data is mainly used to determine the angle of the fridge door so that a picture can be taken at the correct position. Additionaly the orientation is observed to avoid inappropriate pictures, e.g. in case the camera is removed from the fridge shelf.

The sensor data is mainly used to determine the angle of the fridge door so that a picture can be taken at the correct position. Additionaly the orientation is observed to avoid inappropriate pictures, e.g. in case the camera is removed from the fridge shelf.

Light sensor

A light sensor is used to detect the ambience light intensity. This information is used to determine if the camera is correctly placed inside the fridge.

Temperature sensor

A temperature sensor is used to get a reference temperature value. The measured temperature is used for observation of the operation condition.
